A 12 meter manual handwinch telescopic mast for mounting antennas and other equipment. It’s ideal for a variety of telecommunication and broadcast systems.
This 12 meter manual handwinch telescopic mast is a professional-grade component designed for mounting antennas and other equipment. It’s an essential tool for a variety of telecommunication and broadcast systems. The high-quality construction ensures minimal signal loss and long-term durability.
| Extended Height | 12 Meter |
|---|---|
| Retracted Height | 2.3 meter |
| Head Loads | 30 kgs maximum |
| Maximum working air pressure | 0.2MPa |
| Number of sections | 7 |
| Section O.D. range | 6mm~140mm |
| Material | Aluminum Alloy 6063/T5 |
| Default Accessories | 1x Top Flange, 1x Bottom Flange, 1x air hose pipe 2m in length. |
| Mast Net Weight | 55 kgs approx |
